| Product Name | Electrolytic Tinplate Coil (ETP / TFS) |
|---|---|
| Thickness | 0.12mm – 0.60mm |
| Width | 600mm – 1050mm |
| Temper | T1, T2, T2.5, T3, T4, T5, DR7, DR8, DR9 |
| Tin Coating | 1.1 / 2.8 / 5.6 / 8.4 / 11.2 g/m² |
| Standard | ASTM A623/A624, EN 10202, JIS G3303, GB/T 2520 |
| Grade | MR, L, D, SPCC, MR T-2 to T-5 |
| MOQ | 5 Tons |
Tinplate (ETP — Electrolytic Tinplate) is a thin gauge cold rolled steel sheet coated with pure tin on both surfaces through an electrolytic deposition process. The tin coating provides excellent corrosion resistance, non-toxicity, solderability, and an attractive bright surface finish. TFS (Tin Free Steel / ECCS) is also available with chromium/chromium oxide coating as an economical alternative.
Widely used in food and beverage packaging (cans, closures, caps), aerosol containers, chemical cans, paint cans, battery shells, and decorative metal packaging. Available in multiple temper grades from soft forming (T1-T3) to high rigidity (T4-T5, DR7-DR9) to suit different application requirements.
| Attribute | Specification |
|---|---|
| Product Name | Electrolytic Tinplate Coil (ETP) / Tin Free Steel (TFS) |
| Thickness | 0.12mm – 0.60mm (tolerance ±0.005mm) |
| Width | 600mm – 1050mm (slit widths available) |
| Length (Sheet) | 600mm – 1200mm (custom cutting) |
| Base Material | Cold rolled low carbon steel (MR type / L type / D type) |
| Temper (Hardness) | T1 (HR30T 49±3), T2 (HR30T 53±3), T2.5 (HR30T 55±3), T3 (HR30T 57±3), T4 (HR30T 61±3), T5 (HR30T 65±3), DR7 (HR30T 71±3), DR8 (HR30T 73±3), DR9 (HR30T 76±3) |
| Tin Coating Weight | 1.1 / 2.8 / 5.6 / 8.4 / 11.2 g/m² (each side, equal or differential) |
| TFS Coating | Metallic chromium: 50-150 mg/m² / Chromium oxide: 5-35 mg/m² |
| Surface Finish | Bright / Stone / Matte / Silver / LTS (Laser Textured) |
| Standard | ASTM A623/A623M (General), ASTM A624/A624M (DR Tinplate), EN 10202:2001, JIS G3303, GB/T 2520-2017 |
| Steel Grade | MR (Medium Residual — most common), L (Low Residual — high corrosion resistance), D (Aluminum killed — deep drawing), SPCC |
| Coil ID | 420mm standard |
| Coil Weight | 2 – 8 Tons per coil |
| Lacquer/Lithography | Can be supplied with clear/gold lacquer or printed per customer design (optional) |
| Inspection | Tin coating mass (coulometric method ASTM A630), hardness (HR30T), surface inspection (no pinholes, scratches, oil spots), dimensional check, tensile test (for DR grades) |
| Application | Food cans (vegetables, meat, fish, fruits), beverage cans, aerosol cans, paint/chemical cans, crown caps, twist-off caps, battery jackets, decorative tins |
| MOQ | 5 Tons (1 coil) |
| Supply Ability | 5,000+ Tons/month |
| Delivery Time | 15–25 days after order |
| Price Term | FOB / CIF / CFR |
| Payment | T/T (30% advance, 70% against B/L), L/C at sight |
| Temper | Hardness (HR30T) | Formability | Typical Application |
|---|---|---|---|
| T1 | 49±3 | Excellent deep drawing | Complex drawn cans, nozzles, deep parts |
| T2 | 53±3 | Good drawing | Drawn food cans, irregular shapes |
| T2.5-T3 | 55-57±3 | Moderate drawing | General can bodies, aerosol domes |
| T4 | 61±3 | Limited drawing | Can ends, closures, crown caps, rigid containers |
| T5 | 65±3 | Very limited drawing | Large can ends, rigid panels, pail covers |
| DR7-DR8 | 71-73±3 | None (rigid) | Beverage can ends, easy-open lids, battery shells |
| DR9 | 76±3 | None (very rigid) | High-pressure can ends, industrial components |
All tinplate coils are manufactured under ISO 9001:2015 certified quality management system. Testing includes: tin coating mass (coulometric method per ASTM A630/B545), alloy-tin couple test (ATC value), surface passivation film (cathodic reduction), hardness testing (HR30T Rockwell superficial), surface inspection (visual + optical detection for pinholes and defects), oil film measurement, dimensional inspection. Mill Test Certificates per EN 10204 3.1 provided.
Surface Protection: Dioctyl sebacate (DOS) or acetyl tributyl citrate (ATBC) oil film applied (2-6 mg/m²) for corrosion protection during storage and transport. Food-grade oils available.
Packaging: Coils wrapped with anti-rust paper + PE film, secured with steel strapping, edge protection rings. Wooden pallet base. Eye-to-sky loading. Maximum 3 coils per 20ft container. Humidity indicator cards placed inside wrapping.
Storage: Store in dry, ventilated warehouse at 15-30°C with relative humidity below 60%. Keep away from corrosive chemicals. Use within 3 months for best results. Do not stack more than 2 coils high.
