| Product Name | Hot Rolled / Cold Rolled Carbon Steel Plate (Q235B/Q355B) |
|---|---|
| Thickness | 0.2mm β 400mm (Cold Rolled: 0.2-6mm / Hot Rolled: 2.5-400mm) |
| Width | 600mm β 4500mm |
| Length | 1000mm β 18000mm (custom cut) |
| Process | Hot Rolled (HR) / Cold Rolled (CR) |
| Standard | ASTM A36/A283/A572, EN 10025, GB/T 700/1591, JIS G3101 |
| Grade | Q235B, Q355B, A36, S235JR, S275JR, S355JR, SS400, A283C |
| MOQ | 1 Ton |
Carbon steel plates are flat-rolled steel products manufactured through hot rolling or cold rolling processes from quality steel slabs. Q235B is a general structural carbon steel with excellent weldability and formability, widely used in building structures, bridges, and machinery. Q355B is a high-strength low-alloy structural steel offering superior strength-to-weight ratio, making it ideal for heavy-duty structural applications.
Available in a wide range of thicknesses from thin gauge cold rolled sheets (0.2mm) to heavy plates (400mm). All plates undergo strict quality control including ultrasonic testing, mechanical property verification, and dimensional inspection. Custom cutting, edge preparation, and surface treatment available.
| Attribute | Specification |
|---|---|
| Product Name | Hot Rolled / Cold Rolled Carbon Steel Plate |
| Thickness | CR: 0.2mm β 6.0mm / HR: 2.5mm β 400mm |
| Width | 600mm β 4500mm |
| Length | 1000mm β 18000mm (custom cutting available) |
| Manufacturing Process | Hot Rolled (HR) / Cold Rolled (CR) / Normalized / Quenched & Tempered |
| Standard | ASTM A36/A283/A572/A516, EN 10025-2/3/4, GB/T 700-2006, GB/T 1591-2018, JIS G3101/G3106, DIN 17100 |
| Material Grade | Q235B, Q355B/C/D, A36, A283 Gr.C/D, A572 Gr.50, A516 Gr.60/65/70, S235JR, S275JR, S355JR/J2, SS400, SM490A |
| Surface Treatment | Bare (pickled & oiled), shot blasted & primed, black, galvanized, color coated |
| Edge | Mill edge / Slit edge / Trimmed edge |
| Technique | Hot rolled / Cold rolled / Normalized / Tempered |
| Inspection | Ultrasonic testing (UT), mechanical testing (tensile, yield, elongation, bend, impact), chemical analysis, dimensional verification, surface inspection |
| Application | Building structure, bridge, shipbuilding, pressure vessel, machinery manufacturing, pipeline, automobile, container, offshore platform |
| Tolerance | Per standard or as per client requirement |
| MOQ | 1 Ton |
| Supply Ability | 20,000+ Tons/month |
| Delivery Time | 7β20 days after order confirmation |
| Price Term | FOB / CIF / CFR |
| Payment | T/T (30% advance, 70% against B/L), L/C at sight |
| Grade | Standard | Tensile (MPa) | Yield (MPa) | Elongation (%) | Impact Test |
|---|---|---|---|---|---|
| Q235B | GB/T 700 | 370-500 | β₯235 | β₯26 | 20Β°C β₯27J |
| Q355B | GB/T 1591 | 470-630 | β₯355 | β₯22 | 20Β°C β₯34J |
| A36 | ASTM A36 | 400-550 | β₯250 | β₯20 | β |
| A572 Gr.50 | ASTM A572 | β₯450 | β₯345 | β₯18 | β |
| S235JR | EN 10025-2 | 360-510 | β₯235 | β₯26 | 20Β°C β₯27J |
| S355JR | EN 10025-2 | 470-630 | β₯355 | β₯22 | 20Β°C β₯27J |
| SS400 | JIS G3101 | 400-510 | β₯245 | β₯17 | β |
| A516 Gr.70 | ASTM A516 | 485-620 | β₯260 | β₯21 | -46Β°C β₯27J |
| Type | Thickness (mm) | Width (mm) | Length (mm) | Surface |
|---|---|---|---|---|
| Cold Rolled Sheet | 0.2 β 6.0 | 600 β 2000 | 1000 β 6000 | Bright, smooth |
| Hot Rolled Medium Plate | 2.5 β 60 | 1000 β 3500 | 2000 β 12000 | Black, pickled |
| Hot Rolled Heavy Plate | 60 β 200 | 1500 β 4000 | 3000 β 12000 | Black |
| Hot Rolled Ultra-Heavy Plate | 200 β 400 | 1500 β 4500 | 3000 β 18000 | Black |
| Industry | Specific Use |
|---|---|
| Construction | Building frames, steel structures, bridges, stadiums, high-rise buildings |
| Shipbuilding | Hull plates, deck plates, offshore platforms, marine structures |
| Pressure Vessel | Boiler drums, storage tanks, heat exchangers, reactor shells |
| Machinery | Machine frames, gears, tooling plates, die plates, agricultural equipment |
| Pipeline | Large diameter pipes (spiral/LSAW), fittings, flanges |
| Transportation | Railway cars, truck frames, trailer beds, container panels |
All carbon steel plates are manufactured under ISO 9001 certified quality management system. Testing includes: ultrasonic flaw detection (per ASTM A578/A435 Level I/II), mechanical testing (tensile, yield, elongation, bend, Charpy V-notch impact at specified temperatures), chemical composition analysis (OES spectrometer), dimensional inspection, and surface quality check. Mill Test Certificates (EN 10204 3.1) provided with every shipment. Third-party inspection by SGS, BV, TUV available.
Surface Protection: Hot rolled plates: shot blasted and primed (15-25ΞΌm shop primer) upon request. Cold rolled sheets: anti-rust oil coating. PE/PVC film protection for surface-critical applications.
Packaging: Plates packed in bundles with steel strapping. Wooden pallets or steel skids for heavy plates up to 3 tons per bundle. Edge and corner protectors. Waterproof wrapping for sea freight. Custom labeling per client specification.
Shipping: Container vessel (20ft/40ft) or break bulk for oversized plates. From Tianjin/Qingdao/Shanghai port. 20ft max load: ~28 tons. Delivery worldwide.
Send us your specifications and receive a quote within 24 hours.
