| Product Name | Stainless Steel Plate / Sheet (304/304L/316/316L) |
|---|---|
| Thickness | Cold Rolled: 0.3mm β 6mm | Hot Rolled: 2.5mm β 200mm |
| Width | 1000mm / 1219mm / 1500mm / 2000mm (customizable) |
| Length | 2000mm / 2438mm / 3000mm / 6000mm (custom cut) |
| Surface Finish | 2B / BA / No.1 / No.4 / HL / 8K Mirror / Brush / Etched |
| Grade | 304/304L/316/316L/310S/321/904L/2205/2507 |
| Standard | ASTM A240 / EN 10028 / JIS G4304 / GB/T 3280 |
| MOQ | 1 Ton |
Stainless steel plates and sheets are corrosion-resistant, durable, and versatile flat-rolled products available in multiple grades, finishes, and dimensions. Our 304/304L and 316/316L stainless steel plates offer excellent resistance to oxidation, acids, and harsh environments, making them ideal for chemical processing, food industry, pharmaceutical, marine, and architectural applications.
Manufactured to ASTM A240, EN 10028, and JIS G4304 standards with full mill test certificates. Available in cold rolled (precision surface) and hot rolled (structural/heavy gauge) options. Custom cutting to size available.
| Attribute | Specification |
|---|---|
| Product Name | Stainless Steel Plate / Sheet |
| Material Grade | 304, 304L, 316, 316L, 310S, 321, 904L, 2205 Duplex, 2507 Super Duplex |
| Thickness (Cold Rolled) | 0.3mm β 6.0mm |
| Thickness (Hot Rolled) | 2.5mm β 200mm |
| Width | 1000mm / 1219mm / 1500mm / 2000mm (custom up to 3000mm) |
| Length | 2000mm / 2438mm / 3000mm / 6000mm (custom cut available) |
| Surface Finish | 2B, BA, No.1, No.4, HL, 8K Mirror, Brush, Etched, PVD Color Coated |
| Edge | Mill Edge / Slit Edge |
| Standard | ASTM A240/A480, EN 10028-7, JIS G4304/G4305, GB/T 3280-2015 |
| Certification | ISO 9001, SGS, BV, MTC (Mill Test Certificate) |
| Chemical Composition | Per standard: Cβ€0.08%, Cr 18-20%, Ni 8-12% (304); Cβ€0.03%, Cr 16-18%, Ni 10-14%, Mo 2-3% (316L) |
| Mechanical Properties | Tensile β₯515MPa, Yield β₯205MPa, Elongation β₯40% (304) |
| Density | 7.93 g/cmΒ³ (304) / 8.00 g/cmΒ³ (316) |
| MOQ | 1 Ton |
| Supply Ability | 5,000+ Tons/month |
| Delivery Time | 7β25 days after order confirmation |
| Price Term | FOB / CIF / CFR |
| Payment Terms | T/T (30% advance, 70% against B/L), L/C at sight |
| Grade | Type | Key Features | Typical Applications |
|---|---|---|---|
| 304 | Austenitic | Excellent corrosion resistance, good formability, most common grade | Kitchen equipment, architectural, chemical containers |
| 304L | Austenitic | Low carbon version of 304, better weldability, reduced carbide precipitation | Welded components, pressure vessels |
| 316 | Austenitic | Molybdenum added for superior chloride/pitting resistance | Marine equipment, chemical processing, pharmaceutical |
| 316L | Austenitic | Low carbon 316, excellent for welding without post-weld annealing | Surgical implants, coastal architecture, food processing |
| 310S | Austenitic | High temperature oxidation resistance up to 1150Β°C | Furnace parts, heat exchangers, kilns |
| 904L | Super Austenitic | Outstanding resistance to sulfuric acid and chloride environments | Chemical plants, offshore platforms, seawater systems |
| 2205 | Duplex | Twice the strength of 304/316, excellent stress corrosion cracking resistance | Oil & gas, desalination, bridges |
| Finish | Description | Typical Use |
|---|---|---|
| 2B | Cold rolled, annealed, pickled, skin passed β smooth, reflective grey | General industrial, chemical equipment |
| BA | Bright annealed β highly reflective, mirror-like | Architectural trim, kitchenware |
| No.1 | Hot rolled, annealed, pickled β rough, dull finish | Structural, industrial tanks |
| No.4 | Brushed finish with 150-180 grit β short parallel polishing lines | Architectural panels, elevators, kitchen equipment |
| HL | Hairline finish β continuous long grain texture | Decorative panels, escalators, wall cladding |
| 8K Mirror | Highly polished mirror finish β distortion-free reflection | Luxury architecture, decorative, mirrors |
| PVD Coated | Physical vapor deposition color coating β gold, rose gold, black, blue | Premium decorative, hotel lobbies, signage |
All stainless steel plates undergo rigorous quality control: PMI (Positive Material Identification) testing, ultrasonic thickness measurement, surface inspection, dimensional verification, and mechanical property testing. Mill Test Certificates (MTC) per EN 10204 3.1 provided with every shipment. Third-party inspection (SGS, BV, TUV) available upon request.
Packaging: PVC/PE film surface protection (single or double side), waterproof kraft paper wrapping, bundled with steel straps on wooden pallets or in seaworthy wooden crates. Corner and edge protectors applied. Custom labeling and marking available.
Shipping: Container vessel from Tianjin/Qingdao/Shanghai port. 20ft container: ~25 tons; 40ft container: ~27 tons. Break bulk shipment available for oversized plates.
