| Product Name | Pipe Elbow (45°/90°/180° LR/SR Butt Weld) |
|---|---|
| Size | DN15 – DN1200 (1/2" – 48") |
| WT | Sch5S – Sch160 / XXS |
| Angle | 45° / 90° / 180° (custom angles available) |
| Type | LR (Long Radius 1.5D) / SR (Short Radius 1.0D) |
| Standard | ASME B16.9, ASME B16.28, EN 10253, JIS B2311 |
| Material | Carbon Steel / Stainless Steel / Alloy Steel |
| MOQ | 10 pieces |
Pipe elbows are essential pipe fittings used to change the direction of flow in piping systems. Available in 45°, 90°, and 180° angles with Long Radius (LR = 1.5D, most common) or Short Radius (SR = 1.0D, for tight spaces) configurations. Manufactured from seamless or welded pipe/tube through hot forming, cold forming, or mandrel bending processes.
Materials include carbon steel (ASTM A234 WPB), stainless steel (ASTM A403 WP304/316L), and alloy steel (ASTM A234 WP11/WP22) for various temperature and pressure applications. Butt weld ends per ASME B16.25 for welding to matching pipe.
| Attribute | Specification |
|---|---|
| Product Name | Pipe Elbow (Butt Weld) |
| Size Range | DN15 – DN1200 (1/2" – 48") |
| Wall Thickness | Sch5S, Sch10S, Sch20, Sch40/STD, Sch80/XS, Sch160, XXS |
| Angle | 45°, 90°, 180° (custom: 30°/60° available) |
| Type | LR (Long Radius, R=1.5D) / SR (Short Radius, R=1.0D) / 3D/5D elbows |
| Standard | ASME B16.9 (factory-made butt weld), ASME B16.28 (short radius), EN 10253-2/3/4, JIS B2311/B2312, GB/T 12459 |
| Carbon Steel Grades | ASTM A234 WPB, WPC, WPL6 (low temp); 20#, Q235, 16Mn; STPG370 |
| Stainless Grades | ASTM A403 WP304/304L, WP316/316L, WP321, WP310S; 0Cr18Ni9, 00Cr17Ni14Mo2 |
| Alloy Steel Grades | ASTM A234 WP11, WP22, WP5, WP9; 15CrMoG, 12Cr1MoVG |
| End Type | Butt weld (bevelled per ASME B16.25, 30°-37.5°) |
| Surface | Black (carbon steel), pickled & passivated (stainless), shot blasted, anti-rust oil, galvanized |
| Inspection | Chemical (OES/PMI), mechanical, hydrostatic, UT/RT (per order), dimensional (OD, WT, center-to-face, angle), visual |
| Application | Oil & gas pipelines, chemical & petrochemical plants, power generation, shipbuilding, water treatment, HVAC, food & beverage, pharmaceutical piping |
| MOQ | 10 pieces (sample available) |
| Supply Ability | 10,000+ Pieces/month |
| Delivery Time | 5–15 days (stock); 15–30 days (production) |
| Price Term | FOB / CIF / CFR |
| Payment | T/T, L/C |
ISO 9001 / PED 2014/68/EU certified. Testing: PMI (100%), chemical (OES), mechanical (tensile, yield, elongation, hardness, impact), hydrostatic, dimensional, visual. MTC EN 10204 3.1 with full traceability.
Packaging: Wooden pallets/crates, sorted by size and grade. Plastic end caps on bevelled ends. Anti-rust oil for carbon steel. Individual PE bag for stainless
Send us your specifications and receive a quote within 24 hours.
